    Product Image

    SO-E; 20x5 mm; 130.20x5.081

    Orderhint:
    The cups are delivered fully assembled with fitting.
    The listed fittings are spare parts.
    Product Dimensional Drawing Image
    DesignationValue
    H15.5 mm
    Ø dn2 mm
    G1M6
    hg4 mm
    h13.5 mm
    h31 mm
    L20 mm
    B5 mm
    b7 mm
    Here you will find all available documents, such as data sheets, certificates, and much more.
    FileFilesizeActions
    datasheet-bds-fipa-so-e-oval-sauggreifer-en-master.pdf413.58 KB Download
    Vacuum-cups-materials-overview_en.pdf933.04 KB Download
