    Product Image

    Throttle valve, straight, Ø 4 mm (2x)

    • Limits suction performance while maintaining a constant vacuum level for stable and reliable processes
    • Reduces leakage at unoccupied suction cups: Maintains sufficient vacuum at cups holding a workpiece and prevents accidental dropping
    • Manual adjustment of suction performance via knurled screw
    • Easy installation directly into the hose line
    Product Dimensional Drawing Image
    DesignationValue
    Ø D4.0 mm
    B11.0 mm
    A37.5 mm
    C29.5 mm
    D14.0 mm
    d23.2 mm
    Here you will find all available documents, such as data sheets, certificates, and much more.
    FileFilesizeActions
    datasheet-bds-fipa-32-540-inline-drosselventile-en-master.pdf273.96 KB Download
    Here you can find all documents about this product.
