    Product Image
    More items

    Heavy-duty ejector, nozzle diameter, 4x1.3 mm, suction power: 130 Nl/min, max. vacuum 85 %

    SKU:65.130

    Login to see the price
    Loading...
    • Robust and compact aluminum housing
    • Compensation of compressed air fluctuations between 3 and 6 bar (43.5 and 87 psi)
    • Additional inlet for blow-off for fast product release or vacuum switch connection for process monitoring
    • Rectangular design enables block assembly in centralized or decentralized vacuum systems
    Product Dimensional Drawing Image
    DesignationValue
    G1G1/4
    G2G1/2
    B40.0 mm
    A60.0 mm
    C40.0 mm
    G3G1
    D25.0 mm
    E34.0 mm
    G4G1/8
    G5M6
    Here you will find all available documents, such as data sheets, certificates, and much more.
    FileFilesizeActions
    datasheet-bds-fipa-65-102a-heavy-duty-ejektoren-en-master.pdf1.12 MB Download
    Ejectors-Overview_en.pdf1.1 MB Download
    Here you can find all documents about this product.

    Please login to download CAD files

    CAD files are only made available to registered users. Please log in with your existing FIPA customer account or create a new customer account.
